Survision LPR Cameras

Cameras Comparison Table

Compare all characteristics of our LPR Cameras

  Nanopak Micropak Visipak Citypak Picopak
  Nanopak LPR Camera Micropak LPR Camera Visipak LPR Camera CityPak LPR Camera PicoPak LPR Canera
Compact
High Accuracy
Free-flow or Triggered
Flexible Installation
Shared SDK
All license plates
Embedded Recognition AI engine
Max Vehicle Speed: 155 mph (250 km/h)
Type of use In-barrier or in-totem integration Fixed installations Fixed installations Fixed installations Mobile
vehicle installation
Recognition Distance (America)   5 ft to 18 ft
(1.5 m to 5.5 m)
 5 ft to 32 ft
(1.5 m to 10 m)
 23 ft to 92 ft
(7 m to 28 m).
 23 ft to 92 ft
(7 m to 28 m)
 10 ft to 33 ft
(3 m to 10 m)
Recognition Distance (Europe)  6.5 ft to 24.5 ft
(2 m to 7.5 m)
 6.5 ft to 49 ft
(2 m to 15 m)
 23 ft to 116 ft
(7 m to 35 m)
 23 ft to 116 ft
(7 m to 35 m)
 From 13 ft to 51 ft
(4 m to 15.5 m)
Coverage Width  1 lane  1 lane  2 lanes  2 lanes
  Nanopak Micropak Visipak Citypak PicoPak
Image Overview Option
Recognition DGPR (Dangerous
Goods Plates)

Instant Speed Calculation
Confidence Ratio
Realtime RTSP Video Flow
Embedded 4G Modem
Wifi Connectivity
Average Power Consumption 7 W 7 W 15 W 19 W 6 W
Weight 1 lbs (490 g) 3.5 lbs (1.58 kg) 5.5 lbs (2.5 kg) 5.5 lb (2.5 kg) 1.40 lbs (600 g)
Dimensions (LxWxH) in Inches 3.14 x 2.63 x 4.8 4.53 x 2.76 x 5.12 9 x 2.76 x 5.12 9 x 2.76 x 5.12 3.86 x 4.22 x 1.57
Dimensions (LxWxH) in mm 140 x 80 x 1000  130 x 115 x 70  130 x 230 x 70  130 x 230 x 70  107 x 98 x 40
Embedded POE
Water & Dust Protection IP2X IP67 IP67 IP67 IP67 - IK07
Operating Temperature: -40°F to +131°F (-40°C to +55°C)
  Nanopak Micropak Visipak Citypak Picopak
Cybersecurity: SSL (TLS 1.2), 802.1x, 802.1q
NTP
SURVISION Open Camera Development Kit (CDK)
Integrated Wiegand
Serial RS485
Ethernet 10/100
Input Contact for Triggering
Output Contact for Barrier
OSDP
Rest Interface

Common Features

All License Plates

Despite the country or region, even Vanity Plates!

Compact, All included

Lights, protection and connection are integrated into the LPR Cameras

No LPR Server Needed

LPR is performed in the LPR cameras firmware

Free-flow or Triggered

LPR can be triggered by external device or by the license plate itself

AI powered firmware

Neural networks are used to learn from every plate read and increase performance over time

High Vehicle speed

Up to 155 mph (250 km/h)

Short, Fast & Accurate

The shortest distance (from 5ft!) at the highest accurate reading speed (20ms)

One camera per lane

You do not need more than 1 Survision LPR camera to get LPR working

Shared SDK

Software tools for system integration or app building
